Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6
Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6 management. Press to enter the
sub-menu.
OC Profile Save to USB
Saves OC profile to the USB flash disk drive. The USB flash disk should be
FAT32 format only.
OC Profile Load from USB
Loads OC profile from the USB flash disk drive. The USB flash disk should be
FAT32 format only.
CPU Specifications
Press to enter the sub-menu. This sub-menu displays the information of
installed CPU. You can also access this information menu at any time by pressing
[F4]. Read only.
CPU Technology Support
Press to enter the sub-menu. The sub-menu shows what the key
features does the installed CPU support. Read only.
MEMORY-Z
Press to enter the sub-menu. This sub-menu displays all the settings and
timings of installed memory.
CPU Features
Press to enter the sub-menu.
AMD Cool’n’Quiet [Auto]
Enabled or disabled AMD Cool’n’Quiet function.
[Auto] Depends on AMD Design.
[Enable] Enables AMD Cool’n’Quiet function. The Cool’n’Quiet
technology can effectively and dynamically lower CPU speed
and power consumption.
[Disabled] Disables this function.
Important
When adjust CPU Ratio setting then Cool’n’Quiet function will be disabled
automatically. For CPU which supports the Turbo Core Tech., please set AMD Turbo
Core Technology and AMD Cool’n’Quiet as Disabled to retain the default CPU core
speed.
SVM Mode [Enabled]
Enables or disables CPU Virtualization.
[Enabled]
Enables CPU Virtualization and allows a platform to run
multiple operating systems in independent partitions. The
system can function as multiple systems virtually.
[Disabled] Disables this function.
▶
▶
▶
▶
▶
▶
▶
▶
▶
