2-15
MS-7693
Chapter 2
HT Lnk Control
Press
HT Incomng/ Outgong Lnk Wdth
These tems allow you to set the Hyper-Transport Lnk wdth. Settng to [Auto], the
system wll detect the HT lnk wdth automatcally.
DRAM Voltage/ SB Voltage/ NB Voltage/ CPU Voltage/ CPU-NB Voltage
These tems are used to adjust the voltage of CPU, Memory and chpset.
Spread Spectrum
Ths functon reduces the EMI (Electromagnetc Interference) generated by modulatng
clock generator pulses.
Important
If you do not have any EMI problem, leave the settng at [Dsabled] for optmal system
stablty and performance. But f you are plagued by EMI, select the value of Spread
Spectrum for EMI reducton.
The greater the Spread Spectrum value s, the greater the EMI s reduced, and the
system wll become less stable. For the most sutable Spread Spectrum value, please
consult your local EMI regulaton.
Remember to dsable Spread Spectrum f you are overclockng because even a slght
jtter can ntroduce a temporary boost n clock speed whch may just cause your
overclocked processor to lock up.
Overclockng Profiles
Press
Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Press
Set Name for Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
Save Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Save the current overclockng settngs to ROM for selected profile.
Load/ Clear Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Load/ Clear the stored profile settngs from ROM.
Overclockng Profile Save
Save the current overclockng settngs to USB flash dsk.
Overclockng Profile Load
Load the stored settngs from USB flash dsk.
MEMORY-Z
Press
tmngs of your DIMMs. Ths nformaton wll vary by model and s read-only. You can
also access ths nformaton at any tme by pressng [F5]. Press
sub-menu.
▶
▶
▶
▶
•
•
•
▶
▶
▶
▶
▶
▶
▶
▶
