Back Panel Quck Gude
Mouse/Keyboard
A combnaton PS/2 ® mouse/keyboard DIN connector for a PS/2 ® mouse/keyboard.
USB 2.0 Port
The USB 2.0 port s for attachng USB 2.0 devces such as keyboard, mouse, or other
USB 2.0-compatble devces.
USB 3.0 Port
USB 3.0 port s backward-compatble wth USB 2.0 devces. It supports data transfer
rate up to 5 Gbt/s (SuperSpeed).
Important
In order to use USB 3.0 devces, you must connect to a USB 3.0 port. If a USB cable s
used, t must be USB 3.0 complant.
HDMI Port
The Hgh-Definton Multmeda Interface (HDMI) s an all-dgtal audo-vdeo nterface
that s capable of transmttng uncompressed streams. HDMI supports all types of TV
formats, ncludng standard, enhanced, or hgh-definton vdeo, plus mult-channel
dgtal audo on a sngle cable.
DVI-D Port
The DVI-D (Dgtal Vsual Interface- Dgtal) connector can be connected to a LCD
montor, or a CRT montor wth an adapter. To connect a montor, please refer to the
montor’s manual for more nformaton.
VGA Port
The DB15-pn female connector s provded for montor.
▶
▶
▶
▶
▶
▶
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
USB 3.0 Port
LAN
Mouse/Keyboard
USB 2.0 Port HDMI Port
VGA Port
DVI-D Port
