Chapter 1
1-28 Getting Started
JLPT1: Parallel Port Connector
This connector is used to connect an optional parallel port bracket. The parallel port
is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended
Capabilities Parallel Port (ECP) mode.
10.G
roun
d
14.G
roun
d
8.LP
T_S
LIN#
12.G
roun
d
6.PIN
IT#
4.ER
R#
2.AF
D#
24.G
roun
d
22.G
roun
d
26.N
o Pin
20.G
roun
d
18.G
roun
d
16.G
roun
d
1.RS
TB#
3.PR
ND0
5.PR
ND1
7.PR
ND2
9.PR
ND3
11.P
RND
4
13.P
RND
5
15.P
RND
6
17.P
RND
7
19.A
CK#
21.B
USY
23.P
E
25.S
LCT
JCI1: Chassis Intrusion Connector
This connector connects to the chassis intrusion switch cable. If the computer case is
opened, the chassis intrusion mechanism will be activated. The system will record this
intrusion and a warning message will flash on screen. To clear the warning, you must
enter the BIOS utility and clear the record.
2.CIN
TRU
1.Gro
und
