English, Voltage setting, Other setting – MSI H97M-E35 User Manual
Page 28
English
28
DRAM Timing Mode [Auto]
Selects the memory timing mode.
[Auto]
DRAM timings will be determined based on SPD (Serial Presence
Detect) of installed memory modules.
[Link]
Allows user to configure the DRAM timing manually for all memory
channel.
[UnLink]
Allows user to configure the DRAM timing manually for respective
memory channel.
Advanced DRAM Configuration
Press
[Link] or [Unlink] in “DRAM Timing Mode”. User can set the memory timing for each
memory channel. The system may become unstable or unbootable after changing
memory timing. If it occurs, please clear the CMOS data and restore the default
settings. (Refer to the Clear CMOS jumper/ button section to clear the CMOS data,
and enter the BIOS to load the default settings.)
Memory Fast Boot [Auto]
Enables or disables the initiation and training for memory every booting.
[Auto]
This setting will be configured automatically by BIOS.
[Enabled]
Memory will completely imitate the archive of first initiation and
first training. After that, the memory will not be initialed and trained
when booting to accelerate the system booting time.
[Disabled]
The memory will be initialed and trained every booting.
< Voltage Setting >
DRAM Voltage [Auto]
Sets the memory voltage. If set to "Auto", BIOS will set the voltage automatically or
you can set it manually.
< Other Setting >
CPU Memory Changed Detect [Enabled]*
Enables or disables the system to issue a warning message during boot when the
CPU or memory has been replaced.
[Enabled]
The system will issue a warning message during boot and than
needs to load the default settings for new devices.
[Disabled]
Disables this function and keeps the current BIOS settings.
CPU Specifications
Press
installed CPU. You can also access this information menu at any time by pressing
[F4]. Read only.
CPU Technology Support
Press
features does the installed CPU support. Read only.
▶
▶
▶
▶
▶
▶
▶
