Chapter 3
3-12
BIOS Setup
Serial (COM) Port 0 Settings [Auto]
Sets serial port 0 (COM). If set to "Auto", BIOS will optimize the IRQ
automatically or you can set it manually.
Parallel (LPT) Port Configuration
Sets detailed configuration of parallel port (LPT). Press
menu.
Parallel (LPT) Port [Enabled]
Enables or disables parallel(LPT) port.
Parallel (LPT) Port Settings [Auto]
Sets parallel port (LPT). If set to "Auto", BIOS will optimize the IRQ
automatically or you can set it manually.
Device Mode [Printer Mode]
Selects an operating mode for parallel port.
[Printer Mode]
Printer port mode
[SPP]
Standard Parallel Port mode
[EPP-1.9/ 1.7 + SPP] Enhanced Parallel Port-1.9/ 1.7 mode + Standard
Parallel Port mode.
[ECP]
Extended Capability Port mode
[ECP + EPP-1.9/ 1.7] Extended Capability Port mode + Enhanced Parallel
Port-1.9/ 1.7 mode.
Intel(R) Smart Connect Configuration
Sets Intel Smart Connect Technology for optimizing system network performance in
sleep mode. Press
Intel(R) Smart Connect Technology [Enabled]
Enables or disables Intel(R) Smart Connect Technology. This feature can update
applications (ex. email and social networks) by periodically waking your system
from sleep mode. And you do not need to wait for the applications to update when
you wake up the system.
[Enabled]
Enables Intel smart connect technology.
[Disabled]
Disables Intel smart connect technology.
Power Management Setup
Sets system Power Management of EuP2013 and AC Power Loss behaviors. Press
EuP 2013 [Disabled]
Enables or disables the system power consumption according to EuP2013
regulation.
[Enabled]
Optimize the system power consumption according to EuP 2013
regulation.
[Disabled]
Disables this function.
Note: When enabled, the system will not support S4 & S5 wake up by USB, PCI
and PCIe devices.
▶
▶
▶
▶
▶
▶
▶
▶
▶
