Chapter 1
1-4 Getting Started
Motherboard Specifications
CPU
Support
4th Generation Intel ® Core™ i7 / Core™ i5 / Core™ i3 / Pentium ® /
Celeron ® processors for LGA 1150 socket
■
Chipset Intel ® B85 Express Chipset ■
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 1600/ 1333/ 1066 MHz
Dual channel memory architecture
Supports non-ECC, un-buffered memory
Supports Intel ® Extreme Memory Profile (XMP)
■
■
■
■
■
Expansion
Slots
2x PCIe x16 slots
PCI_E1 supports PCIe 3.0
PCI_E4 supports PCIe 2.0
Support x16, x16/x4 modes
2x PCIe 2.0 x1 slots
■
-
-
-
■
Onboard
Graphics
1x VGA port, supporting a maximum resolution of 1920x1200 @
60Hz, 24bpp
1x DVI-D port, supporting a maximum resolution of 1920x1200 @
60Hz, 24bpp
1x HDMI port, supporting a maximum resolution of
4096x2160@24Hz, 24bpp/ 2560x1600@60Hz, 24bpp/
1920x1080@60Hz, 36bpp
1x DisplayPort, supporting a maximum resolution of
4096x2160@24Hz, 24bpp/ 3840x2160@60Hz, 24bpp
■
■
■
■
Multi-GPU
Support
Supports AMD CrossFire TM Technology ■
Storage Intel B85 Express Chipset
4x SATA 6Gb/s ports (SATA1, SATA2, SATA3, SATA4)
2x SATA 3Gb/s ports (SATA5, SATA6)
Supports Intel Smart Connect Technology*
* Supports Intel Core processors on Windows 7 and Windows 8.
■
-
-
-
USB Intel B85 Express Chipset
4x USB 3.0 ports (2 ports on the back panel, 2 ports available
through the internal USB connectors)
8x USB 2.0 ports (4 ports on the back panel, 4 ports available
through the internal USB connectors)
■
-
-
Audio Realtek ® ALC1150 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
■
-
-
LAN 1x Killer E2205 Gigabit LAN controller*
* The Killer Network Manager is only available for Windows 7 and Windows 8 currently.
The supported drivers for other operating systems would be available on the website if
provided by vendor.
■
