1-5 Getting Started
Wireless
LAN
Wi-Fi/Bluetooth expansion module with Intel ® Centrion Wireless-N
2230 chip.**
Supports Wi-Fi 802.11 b/g/n, dual band up to 300 Mbps speed.**
Supports Intel ® Wireless Display (WiDi)**
** For Z87 MPOWER only.
■
-
-
Bluetooth Wi-Fi/Bluetooth expansion module with Intel Centrion Wireless-N
2230 chip.**
Supports Bluetooth v4.0 (includes BLE* and Bluetooth
3.0+HS).**
* BLE: Bluetooth Low Energy
** For Z87 MPOWER only.
■
-
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
2x USB 2.0 ports
1x Clear CMOS button
6x USB 3.0 ports
1x LAN (RJ45) port
1x Optical S/PDIF OUT connector
2x HDMI ports
1x DisplayPort
6x OFC audio jacks
■
■
■
■
■
■
■
■
■
Internal
Connectors
1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connectors
8x SATA 6Gb/s connectors
3x USB 2.0 connectors (supports additional 6 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
2x 4-pin CPU fan connectors
3x 4-pin System fan connectors
1x Clear CMOS jumper
1x Discharge jumper
1x Front panel audio connector
2x System panel connectors
1x TPM module connector
1x Chassis Intrusion connector
14x V-Check points (7x V-Check connectors, 7x V-Check spots)
1x GO2BIOS button
1x Power button
1x Reset button
2x Base Clock control buttons
1x OC Genie button
1x Multi-BIOS switch
1x OC Genie mode switch
1x 2-Digit Debug Code LED
1x Wi-Fi/ Bluetooth module connector
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
I/O
Controller
NUVOTON NCT6779 Controller Chip ■
Hardware
Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
■
■
■
