tlantic Model 162 PBM High Performance Subwoofer
10
Specifications
Bass Driver 8" high efficiency treated cone
Output Power 75W
Frequency Response (LPF at max.) 30Hz – 270Hz,
±
6dB
Low Pass Filter (continuously variable) 60Hz – 125Hz, 24dB/octave
Inputs
High Level (speaker) Left and right high level speaker
Low Level (line) Left and right low level RCA
Throughputs
High Level (speaker) Left and right high level speaker, unity gain
Low Level (line) Left and right low level RCA, unity gain
Input Level continuously variable input gain control
Input Impedance
High Level (speaker) 1.2k
Ω
Low Level (line) 10k
Ω
Dimensions (W X H X D) 10 x 14.4 x 12.4in 255 x 365 x 315mm
Weight 22.75lbs 10.34kg
Power Consumption (standby mode) 18W
Power Requirements 110/240VAC 50/60Hz 200W max.
Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice.
Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation.
For Future Reference
Record your speaker serial number and date of purchase here:
Model Number Serial Number Date of Purchase
The serial number is found on the back of the speaker near the connecting terminals.
