3.2.3 Query
The query function provides information about the functions implemented for each parameter. There
are two type of query function: single query and a query all functions.
The single query will return true (1) or false (0) indicating if the function for the specified function,
attribute, parameter combination is implemented.
The query all will return a value where the binary digits indicate where specific functions/attribute
combination as been implemented. Set the function value to avParFunc_queryAll in the following
packet.
3.2.3.1 Query Request Packet
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
‘A’ ‘P’ ‘A’ paramID attribute value ‘A’
Where
‘A’, ‘P’ are literal ASCII characters.
paramID is the parameter identifier being queried.
attribute is the attribute identifier being queried.
value is the function being queried (see the following table).
Function to be queried:
Identifier
Value Base 64 Description
avParFunc_get 0 AAAAAA Query the get value function.
avParFunc_set 1 AAAAAB Query the set value function.
avParFunc_gets 2 AAAAAC Query the get string function.
avParFunc_sets 3 AAAAAD Query the set string function.
avParFunc_queryAll 4 AAAAAE Query all the parameter functions.
For query all set attribute to avParamAttr_avail.
3.2.3.2 Query Reply
On successful completion the query function will return a value see “
3.2.2.2 Success Reply Packet
with return value”.
For a single query function call the possible values returned will be:
0 (AAAAAA in base 64) for false
1 (AAAAAB in base 64) for true
For a query all function call the value return will be a binary bit pattern. Specific binary digits represent
true or false indicating if specific functions are implemented.
These are the bit masks to identify each function flag:
Identifier
Bit Base 16 Description
avQueryFunc_get_avail 0 0x0001 Availability function for parameter.
avQueryFunc_get_availValue 1 0x0002 Availability function for specific value.
avQueryFunc_get_min 2 0x0004 Function that returns the minimum
value.
avQueryFunc_get_max 3 0x0008 Function that returns the maximum
value.
avQueryFunc_get_val 4 0x0010 Get value function.
avQueryFunc_get_e2val 5 0x0020 Get value function (NV).
avQueryFunc_set_val 6 0x0040 Set value function (live).
avQueryFunc_set_e2val 7 0x0080 Set value function (NV/Save).
avQueryFunc_gets 8 0x0100 Get string function.
avQueryFunc_sets 9 0x0200 Set string function.
