Overview
5
3.1 FC-47 / FC-48 Input/Output Resolutions
This section describes the:
• FC-47 PC input/output resolutions, see Table 1
• FC-47 HD input/output resolutions, see Table 2
• FC-48 PC input/output resolutions, see Table 3
• FC-48 HDTV input/output resolutions, see Table 4
Table 1: FC-47 PC Input/Output Resolutions
VGA
1 VGA @60Hz
1 @72Hz VGA 1 @75Hz VGA 1 @85Hz
SVGA
2 SVGA @60Hz
2
@72Hz SVGA
2
@75Hz SVGA
2
@85Hz
XGA
3 XGA @60Hz
3
@70Hz XGA
3
@75Hz XGA
3
@85Hz
XGA
3
@87Hz SXGA
4 SXGA @60Hz
4
@75Hz SXGA
4
@85Hz
UXGA
5 1152@70Hz @60Hz 1152@75Hz 1152@85Hz
Table 2: FC-47 HD Input/Output Resolutions
480i@60Hz 576i@50Hz 480P@60Hz 576P@50Hz 720P@60Hz
720P@50Hz 1080i@60Hz 1080i@50Hz 1080P@60Hz 1080P@50Hz
1080P@30Hz 1080P@25Hz 1080P@24Hz
Table 3: FC-48 PC Input/Output Resolutions
VGA 1 @60Hz VGA 1 @72Hz VGA 1 @75Hz VGA 1 @85Hz
SVGA 2 @60Hz SVGA 2 @72Hz SVGA 2 @75Hz SVGA 2 @85Hz
XGA 3 @60Hz XGA 3 @70Hz XGA 3 @75Hz XGA 3 @85Hz
XGA
3
@87Hz SXGA
4
@60Hz SXGA
4
@75Hz SXGA
4
@85Hz
UXGA
5
@60Hz 1152@70Hz 1152@75Hz 1152@85Hz
Table 4: FC-48 HDTV Input/Output Resolutions
480P@60Hz 576P@50Hz 720P@50Hz 720P@60Hz 1080i@50Hz
1080i@60Hz 1080P@60Hz 1080P@50Hz 1080P@30Hz 1080P@25Hz
1080P@24Hz
1 640x480
2 800x600
3 1024x768
4 1280x1024
5 1600x1200
