Connecting the VP-210K UXGA Line Amplifier
5
Table 1: VP-210K UXGA Line Amplifier Features
# Feature Function
1 LOOP 15-pin HD (F) Connector Connects to a local display
2 OUTPUT 15-pin HD (F) Connector Connects to the computer graphics acceptor
3 HI-Z/75 DIP-switches Set to 75 TERM (when a local monitor is not used); set to
Hi-Z (when a local monitor is connected to the LOOP 15-pin
HD connector)
4 5V DC +5V DC connector for powering the unit
5 EQ. Control knob Adjusts the video EQ. (equalization) compensation
6 LEVEL Control knob Adjusts the video signal level
7 INPUT 15-pin HD (F) Connector Connect to the computer graphics source
8 ON LED Illuminates when receiving power
5 Connecting the VP-210K UXGA Line Amplifier
To connect your VP-210K UXGA Line Amplifier, as shown in the example in
Figure 2, do the following 1 :
1. Connect a computer graphics source (for example, a computer) to the
INPUT 15-pin HD (F) connector.
2. Connect the OUTPUT 15-pin HD (F) connector to an acceptor (for
example, a projector).
3. Connect the LOOP 15-pin HD (F) connector to an acceptor (for
example, a local display).
4. Connect the 5V DC power adapter to the 5V DC socket and connect the
transformer to the mains electricity (not illustrated in Figure 2).
5. Adjust the video output signal level and/or cable compensation equalization
level as needed.
6. Set the DIP-switches as follows:
If no terminal is attached to the LOOP connector, set the
switches down to 75 TERM
If a terminal is attached to the LOOP connector, set the
switches up to HI-Z
1 Switch OFF the power on each device before connecting it to your VP-210K. After powering up your VP-210K, switch on
the power on each device
