Technical Specifications
8
7 Technical Specifications
Table 3 includes the technical specifications
1
of the
VM-5DS:
Table 3: Technical Specifications of the VM-5DS
INPUTS:
1 video composite, looping, 1Vpp/75 on BNC connectors with
termination switch
1 audio stereo looping, +4dBm/50k on RCA connectors
OUTPUTS:
5 video composite 1 Vpp/75 on BNC connectors
5 audio stereo, +4dBm/50 , 27 Vpp max. on RCA connectors
1 VGA through WXGA on an HD15F connector
SCALED OUTPUT RESOLUTIONS: VGA (640 x 480), SVGA (800 x 600), XGA (1024 x 768), WXGA (1366 x 768)
MAX. VIDEO OUTPUT LEVEL:
2.2 Vpp
BANDWIDTH (-3dB):
VIDEO: 360MHz
AUDIO: 60kHz
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.06 Deg.
K-FACTOR:
0.05%
S/N RATIO:
VIDEO: 76dB
AUDIO: 0.004%
CONTROLS:
Video gain: -1 to +1.8dB, EQ.: 0 to +2.5dB, audio: 0.2 to +6dB
COUPLING:
VIDEO: DC/AC selectable
AUDIO: AC
AUDIO THD + NOISE:
0.021% (1V, 1kHz.)
POWER SOURCE:
100-240 VAC, 50/60Hz 15 VA
DIMENSIONS:
19-inch (W), 7-inch (D) 1U (H) rack mountable
WEIGHT:
1.94 kg (4.3 lbs.) approx.
ACCESSORIES:
Power cord, rack ears
1 Specifications are subject to change without notice
