3
KRAMER ELECTRONICS LTD.
2. SPECIFICATIONS
VM-3S / VM-3Sxl VM-3V / VM-3Vxl
Function 1:3 s-Video DA 1:3 Composite/Single Component Video
DA
Input 1 s-Video, 1Vpp/75ohm (Y),
0.3Vpp/75ohm (C) on a 4P connector
1 Composite Video, 1Vpp/75ohm, on a
BNC connector
Output Type 3 s-Video, 1Vpp/75ohm (Y),
0.3Vpp/75ohm (C) on 4P connectors
3 Composite Video, 1Vpp/75ohm, on
BNC connectors
Output Coupling AC AC
Controls Termination Switch (VM-3Sxl only) Termination Switch (VM-3Vxl only)
S/N Ratio 70dB (80 dB for VM-3Sxl) 73dB (77dB for VM-3Vxl)
Video Bandwidth 60 MHz -3dB (Y);
(200 MHz –3dB, Y, VM-3Sxl)
60 MHz -3dB;
(430 MHz -3dB,VM-3Vxl)
Max Video Output 2Vpp (Y) 2Vpp
Diff. Gain 0.03% 0.05%
Diff. Phase 0.03Deg. 0.13Deg.
K-Factor 0.4% (0.3% for VM-3Sxl) <0.5% (0.2% for VM-3Vxl)
Dimensions
(W, D, H)
11.7cm x 6cm x 3.2cm
4.6" x 2.4" x 1.3"
11.7cm x 6cm x 3.2cm
4.6" x 2.4" x 1.3"
Weight 0.240kg (0.53lbs) Approx. 0.28kg (0.62lbs.) Approx.
Power consumption 0.84VA 0.6VA
Power Source 12VDC, 70mA 12VDC, 50mA
