Overview
2
In particular, the VM-25:
Includes a looping connector for connecting to a local monitor, other
acceptor, or for forming larger systems 1
Has a video bandwidth of more than 430MHZ, ensuring transparent
performance with typical video sources
Has front panel video trimmer controls
2 for output level (LEVEL) and
cable equalization (EQ.)
Achieving the best performance means:
Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances and
positioning your VM-25 away from moisture, excessive sunlight and dust
Figure 1 and Table 1 define the VM-25 1:25 Video Distribution Amplifier:
1 For example, you can connect 3 VM-25 units to make a 1:75 video distribution amplifier. See section 4.2 for details
2 The video outputs are arranged in two blocks of 5 outputs (outputs 1 to 5, and outputs 6 to 10). Each block can be separately
trimmed for output level and cable equalization (EQ.) thus achieving different compensations for different cable lengths
