3. Interface Specifications
Printer Programming Language B, PPLB
Specification
Model
OS-203DT
Model
OS-204DT
Model
OS-214TT
Model
OS-314TT
General fonts
5 fonts with different point sizes
Symbol sets
(Code pages)
8 bits: code page 437, 850, 852, 860, 863 and 865. 7
bits: USA, British, German, French, Danish, Italian,
Spanish, Swedish and Swiss.
Soft fonts
Downloadable soft fonts
Font
expandability
1x1 to 24x24
Bar code
types
Code 39(checksum), Code 93, Code 128/ subset A,B,C,
Codabar, Interleave 2 of 5(checksum), Matrix 25, UPC
A/E 2 and 5 add-on, EAN-8/13, Code 128UCC,
UCC/EAN, Postnet, German Postcode. MaxiCode and
PDF417 (2D symbologies)
Graphics
PCX and binary raster
Notes :
1. The bare core for ribbon must be 11 cm in length. It should
have two opposite slits at two ends. If the ribbon itself is
less than 11 cm, it has to be aligned with the bare core at
left end when you install it.
2. Since this printer uses band buffer technology, if you just
print texts or barcodes the maximum length can be more
than 30 inches, whereas if you print many graphics the
maximum length can only be few inches under standard
onboard RAM.(The extension RAM, font board and flash
modules use the same connector, they cannot function at
the same time.)
58
Serial
For OS-204/214/314, the RS232 connector on the printer side is a
female, DB-9.
Pin
Direction
Definition
1 In
DSR
2
In
RxData
3
Out
TxData
5
-
Ground
6
Out
DTR
7
Out
RTS
8
In
CTS
9
Out
+5V
For OS-203, the RS232 connector is Mini Dim 6P
.
57
