3
Features:
1. Selectable output voltage (30 VAC or 60 VAC).
2. A simple turn of a knob adjusts power.
3. Lighted
ON/OFF Switch.
4. Circuit protection.
5. 20 WATTS @ 30 VAC. 27 WATTS @ 60 VAC
6. Low profile housing.
General Use:
The Power Controller is used to manually adjust power to a load with a simple turn of a knob. It was designed for use with low
voltage heating mantles. The output voltage is selectable at 30 VAC and 60 VAC. The approximate values for the voltage output
can be found in Table 1¹.
Table 1: Approximate Output Voltages
¹ Actual voltage outputs can be found by using a voltmeter or digital multi-meter across the heating mantle or load.
Knob Setting
(%)
Approximate VAC Output
30 VAC 60 VAC
0 0.2 +/- 2 +/- 5% 0.7 +/- 2 +/- 5%
20 0.2 +/- 2 +/- 5% 0.7 +/- 2 +/- 5%
40 0.2 +/- 2 +/- 5% 15.3 +/- 2 +/- 5%
60 6.2 +/- 2 +/- 5% 28.0 +/- 2 +/- 5%
80 23.0 +/- 2 +/- 5% 46.0 +/- 2 +/- 5%
100 29.5 +/- 2 +/- 5% 57.0 +/- 2 +/- 5%
