CONTROLLER CONFIGURATION factory settings (T type):
LEVEL 1
tune
band
int.t
der.t
dac
cyc.t
ofst
sp.lk
set.2
bnd.2
cyc.2
off
.1
off
off
.5
on.of
0.0
off
0.0
.1
on.of
LEVEL 2
sp1.p
hand
pl.1
pl.2
sp2.a
sp2.b
disp
hi.sc*
lo.sc*
inpt*
unit
100
off
100
100
dv.hi
none
0.1º
250
-199.9
t
ºC
LEVEL 3
sp1.d
sp2.d
burn
rev.d
rev.l
span
zero**
check
read
data
ver
rset
ssd
rly
up.sc
1d2d
1i2n
0.0
#.#
off
var
ct A
3
none
*for Type “K” thermocouple - hi.sc=999.9, lo.sc=-50, inpt=k
**zero value is set at factory
Changing Display from °C to °F
The display units can be changed by depressing both the ▲ and ▼ keys simultaneously. Once “tune” is displayed, the keys may
be released. Then depress the ▼, until “LEVL” is displayed. Depress and hold the * key. Then press the ▲, until the display
reads “2”, then release the * key. Now depress the ▲, until the display reads “unit”. The display will alternate between “°C” and
“unit”. Depress and hold the * key. Then press the ▲ to display “°F”, then release the * button. The change will be saved by
either depressing both the ▲ and ▼ keys simultaneously and releasing when the measured temperature is displayed. Or, if no
other keys a pressed after about 60 seconds the changes will be saved and the measured temperature will be displayed.
Changing Sensitivity of Alarm set point - Factory set to +.1°C
The alarm set point sensitivity can be changed by depressing both the ▲ and ▼ keys simultaneously. Once “tune” is displayed,
the keys may be released. Then press the ▲ until “bnd.2” is displayed. Depress and hold the * key. Then press the ▲ to enter
the desired sensitivity value, then release the * button. The change will be saved by either depressing both the ▲ and ▼ keys
simultaneously and releasing when the measured temperature is displayed. Or, if no other keys a pressed after about 60 seconds
the changes will be saved and the measured temperature will be displayed.
