Page 6
unDIO2x2
User Manual
Attero Tech LLC 2013
Page 5
614-00013-01
2 – Device Installation
1
Power LED
2
Power Socket – Use with optional 12 V DC wall wart only
3
Dante® Ethernet interface connector and indicators
4
2 x Balanced audio inputs
5
2 x Balanced Audio outputs
*Note:
The unDIO2x2 has a label on one of the mounting flanges that shows the last 6 digits of the MAC address. This
is important for initial device identification as these digits make up part of the devices default network name that is
shown when the device is detected by Dante Controller. The full MAC address is also given on the bottom of the unit.
