Silverline Plug-In Mechanical Timer User Manual
Plug-in mechanical timer, 7 day, Ec declaration of conformity

ELECTRICAL SAFETY
• Even when used as prescribed it is not possible to eliminate all residual risk
factors. Use with caution. If you are at all unsure of the correct and safe manner
in which to use this product, do not attempt to use it.
BEFORE USE
UNPACKING
• Carefully unpack your timer. Ensure all packaging materials are removed and
fully familiarise yourself with all features of the product.
• If any parts are damaged or missing, have these parts repaired or replaced
before use.
OPERATING
• To use the timer function, slide the Function Switch (4) down so that the
logo is visible.
• Each black Timer Segment (3), surrounding the Timer Dial (2), represents 2
hours operating time. Push in the black segments corresponding to the period
of time during each day that you want the power to be ON. This 7 day cycle will
repeat every week unless the timer is disconnected from the power.
• Turn the Timer Dial (2) clockwise until the black arrow is pointing at the current
time.
• Connect the timer to the power socket and plug the appliance into the
timer.
• Ensure the switch to the mains power and the switch to the appliance is set to
ON.
• The Power Indication Light (6) will illuminate when the timer enters the
‘working’ mode.
• To override the timer function slide the function switch up to reveal the
logo.
MAINTENANCE
• When storing the timer for any prolonged period of time clean it with a dry
brush so that all debris is removed that could affect the timer function.
148232
Plug-In Mechanical Timer
7 Day
4
2
1
6
5
3
EC Declaration of Conformity
The undersigned: Mr Darrell Morris
as authorised by: Silverline Tools
Declares that the
Product Code: 148232
Description: Plug-In Mechanical Timer
Conforms to the following Directives:
• Low Voltage Directive 2006/95/EC
• RoHS Directive 2011/65/EU
• EN 60730-1:2000+A12: 2003+A1: 2004+A13: 2004+A14:
2005+A16: 2007+A2: 2008
• EN 60730-2-7: 91+A1: 97+A12: 93+A11: 94+A13: 2003+A14
The technical documentation is kept by: Silverline Tools
Notified body: Intertek Testing Services Ltd
Place of declaration: Shanghai, China
Date: 08/01/13
Signed by:
Director
Name and address of Manufacturer or Authorised representative:
Silverline Tools, Boundary Way, Lufton Trading Estate, Yeovil, Somerset,
BA22 8HZ United Kingdom
1) Socket
2) Timer Dial
3) Timer Segments
4) Function Switch
5) Plug
6) Power Indication Light
www.silverlinetools.com
