Parts list – Silverline Air Finishing Nailer 64mm User Manual
Page 42
www.silverlinetools.com
41
955431
No.
Description
Qty
1
Set Screw
1
2
Exhaust Cover
1
3
O-Ring 10.6 x 1.8mm
1
4
O-Ring 47.5 x 1.8mm
1
5
Hex Bolt M5 x 25
6
6
Spring Washer M5
6
7
Flat Washer M5
4
8
Air Cap
1
9
Cap Seal
1
10
Spring
1
11
O-Ring 17.8 x 2.5mm
3
12
Head Valve Piston
1
13
O-Ring 49.5 x 2.4mm
1
14
Gasket
1
15
Lining Ring
1
16
O-Ring 53 x 2.65mm
1
17
O-Ring 31.2 x 3.5mm
1
18
Driver Blade Unit
1
19
O-Ring 41.2 x 2.65mm
1
20
Cylinder
1
21
O-Ring 41.2 x 3.55mm
1
22
Bumper
1
23
Body
1
24
Base Bung
1
25
Safety Guide
1
26
Spring Pin 3 x 25mm
2
27
Spring
1
28
Bend Lever
1
29
Adjust Knob
1
30
Lock Nut M4
4
31
Safety
1
32
No-Mar tip
1
33
Switch Unit
1
34
Spring
1
35
Spring Pin 2.5 x 16mm
2
36
Trigger Lever
1
37
Trigger
1
38
Pin
1
39
O-Ring 1.8 x 1.8mm
1
40
Set Screw M4 x 4
1
41
Cover
1
No.
Description
Qty
42
Spring
1
43
Baffle Board
1
44
Driver Guide
1
45
Lock Plate
1
46
Driver Guide Cover
1
47
Latch Grip
1
48
Quick Release Lever
1
49
Spring Pin 2.5 x 18mm
1
50
E-Ring 3mm
1
51
Pin
1
52
Spring
1
53
Pusher Unit
1
54
Cover Plate
1
55
Orientation Plate
1
56
Nail Guide
2
57
Magazine
1
58
Spring Washer M4
2
59
Hex Bolt M4 x 12
2
60
Set Screw M4 x 10
1
61
Tail Cover
1
62
Spring Pin 3 x 15mm
1
63
Pin
2
64
Clapboard
1
65
Hex Bolt M4 x 10
2
66
Tail Hanger
1
67
Hex Bolt M5 x 18
1
68
Lock Nut M5
1
69
Hand Grip
1
70
Gasket
1
71
End Cap M5 x 20
1
72
Hex Bolt
3
73
Air Plug
1
Parts List
