Owner’s Manual Room Air Conditioner with R-410A Heat Controller, Inc.
9
ADDITIONAL THINGS YOU SHOULD KNOW
Now that you have mastered the operating procedure, here are more features in your control that
you should become familiar with.
The Cool circuit has an automatic 3 minute time delayed start if the unit is turned off and on
quickly. This prevents overheating of the compressor and possible circuit breaker tripping.
The fan will continue to run during this time.
The control will maintain any set temperature within 2 F, between 60 F and 90 F degrees.
The control is capable of displaying temperature in degrees Fahrenheit or degrees Celsius.
To convert from one to the other, press and hold the Up and Down Temp/Timer buttons at the
same time, for 3 seconds.
Fresh Air Vent Control(on some models):
Figure 1 (VENT CLOSED) Figure 2 (VENT OPEN)
The Fresh Air Vent allows the air conditioner to:
1. Recirculate inside air - Vent Closed (See Fig.1)
2. Draw fresh air into the room- Vent Open (see Fig.2)
3. Exchange air from the room and draws fresh air into
the room - Vent and Exhaust Open (see Fig.3)
Figure 3
(VENT & EXHAUST OPEN)
9
Air Directional Louvers
The 4-way air directional louvers allow you to
direct the air flow Up or Down and Left or Right
throughout the room as needed. To adjust the
air directional louvers side-to -side, use the
center handles as you move it side-to-side.
Air Direction(4- way)
TO USE THE CLEAN AIR FEATURE:
(on some models)
Press the
button
DO THIS:
Energy
Saver
on off
Timer
Auto
Fan
Cool
Dry
Mode
TEMP/TIMER
TEMP/TIMER
Clean
Air
Press the Clean Air button, the ion generator is
ener gized and will help to remove pollen and
impurities from the air, and trap them in the filter.
NOTE:
The Cooling circuit has an automatic 3 minute time delayed start if the unit is turned off and on
quickly. This prevents overheating of the compressor and possible tripping of the circuit breaker.
The fan will continue to run during this time.
ADDITIONAL THINGS YOU SHOULD KNOW
Now that you have mastered the operating procedure, here are more features in your control that
you should become familiar with.
The Cool circuit has an automatic 3 minute time delayed start if the unit is turned off and on
quickly. This prevents overheating of the compressor and possible circuit breaker tripping.
The fan will continue to run during this time.
The control will maintain any set temperature within 2 F, between 60 F and 90 F degrees.
The control is capable of displaying temperature in degrees Fahrenheit or degrees Celsius.
To convert from one to the other, press and hold the Up and Down Temp/Timer buttons at the
same time, for 3 seconds.
Fresh Air Vent Control(on some models):
Figure 1 (VENT CLOSED) Figure 2 (VENT OPEN)
The Fresh Air Vent allows the air conditioner to:
1. Recirculate inside air - Vent Closed (See Fig.1)
2. Draw fresh air into the room- Vent Open (see Fig.2)
3. Exchange air from the room and draws fresh air into
the room - Vent and Exhaust Open (see Fig.3)
Figure 3
(VENT & EXHAUST OPEN)
9
Air Directional Louvers
Air Direction(4- way)
TO USE THE CLEAN AIR FEATURE:
(on some models)
Press the
button
DO THIS:
Press the Clean Air button, the ion generator is
ener gized and will help to remove pollen and
impurities from the air, and trap them in the filter.
NOTE:
on off
Timer
Temp/Timer
Clean
Air
Energy
Saver
Temp/Timer
Auto
Cool
Dry
Fan
Mode
Heat
The 4-way air directional louvers allow you to
direct the air flow Up or Down(on some models)
and Left or Right throughout the room as needed.
To adjust the air directional louvers side-to -side,
use the center handles as you move it side-to-side.
AIR CONDITIONER FEATURES(CONTINUED)
Press the Clean Air button, the Ionizer is energized and
will help to remove pollen and impurities from the air,
and trap them in the filter.
CLEAN AIR FEATURE:
