12
OVERALL DIMENSIONS Width: 860 mm.
Depth: 500 mm.
Height: 88 mm.
Weight: 8 Kg.
CUT OUT DIMENSIONS Width: 830 mm.
Depth: 470 mm.
Thickness: 30 mm.
SUPPLY CONNECTIONS Gas:
RC 1/2 inch (1/2 inch male) Rear right hand corner
Electric:
230-240V 50Hz supply, 3 core flexible cable with
non rewireable plug fitted with a 3 amp cartridge fuse.
IGNITION HT SPARK Spark Generator
Ispra Control's BF 50066 - 230-240V 0.6 YA T120
Spark Gap : Fixed
HEAT INPUT
Rear Left Burner (semi rapid) 2.0 kW (6824 BTU/HR)
Front Left Burner (rapid) 3.0 kW Natural Gas (10236 BTU/HR)
2.8 kW L.P.G. (9554 BTU/HR)
Central Burner (double-crown) 3,5 kW (11942 BTU/HR)
Rear Right Burner (semi rapid) 2.0 kW (6824 BTU/HR)
Front Right Burner (auxiliary) 1.0 kW (3412 BTU/HR)
APPLIANCE CLASS 3
APPLIANCE CATEGORY II2H3+
GAS SUPPLY Natural gas G20 / 20mbar
Instructions for the Installer
Engineers technical data
