Vantech H3 Rack 3 Bar System for a GMC Savana 1996-On - Manual (Page 2)

2
SS-B016 5/16” X 1 1/4” CARRIAGE BOLT 4 8 12 16
SS-W008 5/16” X 3/4” WASHER 8 16 24 32
SS-N005 5/16” NYLON NUTS 8 16 24 32
S053 5/16”X 1” DOUBLE SLIDER (3” SEPARATION) 2 4 6 8
A286-65/72 CROSS-BAR (A286) 65”/72” 1 2 3 4
H16/H17 MOUNTING BASE 2 4 6 8
H11 DRIP RAIL MOUNT 2 4 6 8
Z286 ENDCAP (286) 2 4 6 8
BG708 RUBBER SEAT 2 4 6 8`
PART # DESCRIPTION 1BAR 2 BAR 3 BAR 4BAR ITEMS
(NOT DRAWN TO SCALE)
HARDWARE D031/D032/D033
