S P E C I F I C AT I O N S
PAG E 7
SPEC. OF CD/MP3 PLAYER
1. Output Level @ 1kHz, 0dB 1.2V +/- 0.3V
2. Frequency Response 20Hz-20kHz +/- 2dB
3. Separation 1kHz, 0dB >60 dB
4. T.H.D+ Noise 1kHz, 0dB <0.05%
5. S /N Ratio >80 dB
SPEC. OF AM / FM TUNER
FM:
1. Tuning Range 87.5 MHz -108 MHz
2. IF Frequency & Rejection 10.7 MHz >80 dB
3. Image Rejection >25 dB
4. S/N Ratio 1mV/M Input 46db
5. T.H.D 1mV <1.0%
6. Auto Tuning Sens. <50uV
AM:
1. Tuning Range 522kHz - 1620kHz
2. IF Frequency & Rejection 450 kHz >45dB
3. Image Rejection >30dB
4. S/N Ratio 5mV/M Input >35dB
5. Auto Tuning Sens. <2mV
Dimensions: 482 (W) x 44 (H) x 250 (D) mm
