Barksdale, Inc. 3211 Fruitland Avenue, Los Angeles CA 90058 (800)835-1060 www.barksdale.com Bulletin No. 272353-B, 4-3-14

4

5.0 TECHNICAL DATA

5.1 Technical Specification:
Specifications has been mentioned on provided catlog or sales drawing with the product.

Table 2. Product Specifications

5.2 Product Configurator:

Figure 1. Product Configurator for Regulator 20597

EXAMPLE:

20597S6WQ2

Option

Blank

NPT porting

Adjustment Method

 ‐ MS

SAE porting

 ‐ SS

    Stainless steel flanges & trim

Blank   Manual

F

  Pneumatic failsafe motor

G

  Hydraulic failsafe motor

Regulated Pressure Range (Manual)

Blank

High sensitivity 300 ‐ 1600 psi (21 ‐ 110 bar)

‐1

Full range

500 ‐ 3300 psi (34 ‐ 228 bar)

Series

Regulated Pressure Range (Failsafe)

  1‐1/2” Pressure regulator

F & G Models

Blank

High sensitivity 300 ‐ 1600 psi (21 ‐ 110 bar)

‐1

Full range

500 ‐ 3000 psi (34 ‐ 207 bar)

  20597S6WQ2
