6
FINISHING THE INSTALLATION
Step 1. Remove the 1 of 2 screws from the bottom of the hanger bracket and loosen the other one
a half turn from the screw head.
Step 2. Slide the canopy up to hanger bracket and place the key hole on the canopy over the screw
on the hanger bracket, turn canopy until it locks in place at the narrow section of the key holes.
(Fig. 14)
Step 3. Align the circular hole on canopy with the remaining hole on the hanger bracket, secure by
tightening the two set screws, next, while holding the canopy with one hand, slide the canopy
cover over the screws and rotate counter-clockwise until tight.
Note: Adjust the canopy screws as necessary until the canopy and canopy cover are snug.
Fig. 14
CANOPY
CANOPY
COVER
OUTLET BOX
HANGER
BRACKET
HANGER
BALL
CANOPY
CANOPY
COVER
