SWITCH
CUP
8. A
TTACHING THE
S
WITCH
C
UP
Step 1. Remove screws in switch
cup ring. While holding the switch
cup under your fan, snap the wire
c o n n e c t o r p l u g s t o g e t h e r .
(Figure 17). Then push the switch
cup up to switch ring and position
so holes line up. Reinstall screws
and tighten.
Step 2. Attach the pull chain fob
to the chain on the switch cup.
SWITCH
CUP RING
WIRE
CONNECTOR
PLUGS
FIG. 17
Optional
Light
Kit
Wiring
(See
instruc-
tions
included
with the
light kit.)
TEL INNER HOLES ON MOTOR ARE FOR
4 BLADES AND THE OUTER FOR 5BLADES.
Through the bigger hole to attach 4 blades assembly
to motor using the motor screws and washers
provided.
