8 INSTALLING THE SWITCH BOX
PLATE&SWITCH CUP
Step1.Remove 1of 3screws from the mounting ring and loosen the other 2
screws.(Do not remove.) (Fig.17)
Step2.Place the key holes from the switch box plate over the 2 screws previously
loosened from the mounting ring , turn switch box plate until it locks in place
at the narrow section of the key holes. Secure by tightening the 2 screws
previously loosened and the one previously removed.(Fig.17)
Step3.Remove the three screws from the rim of the switch box plate. Align the holes
in the switch cup with the holes in the switch box plate. Tighten the three
screws.(Fig. 17)
17
LOOSENED
SCREWS
SCREWS
mounting
ring
SWITCH BOX
PLATE
SWITCH CUP
