Blade installation – Minka Group F582-ORB User Manual
Page 17
8
Fig 17
THE FOLLOWING OPERATIONS MUST BE ACCOMPLISHED BEFORE INSTALLING THE LIGHT KIT.
Insert one fan blade into the blade slot on the motor housing and secure with the blade support
plates, screws and washers. Securely tighten screws. Repeat process with other blades. (Fig. 17)
BLADE INSTALLATION
BLADE
SLOT
SCREWS
RUBBER
WASHERS
BLADE
SUPPORT
PLATES
