Meteor C192 Controller - Manual (Page 6)

3
RUNNING CHASES:
MANUAL RUN CHASES:
This function will enable you to manually step
through “selected Chase.
1) Press and Hold the PROGRAM BUTTON for three (3)
Seconds to Enter the PROGRAMMING MODE.
2) Start a CHASE by selecting one of the six (6) CHASE
BUTTONS (on right side of Controller)
3) Press the TAP SYNC BUTTON. Each time you press
Button, you will step through the Scenes in the CHASE.
4) Use the BANK SELECT Button to scroll through the
CHASES.
5) PRESS and HOLD the PROGRAM BUTTON for three (3)
seconds to exit the PROGRAMMING MODE.
RUNNING CHASES:
AUTO RUN CHASES:
1) PRESS ANY or all of 6 CHASE BUTTONS (on right side) to
select the desired CHASE to RUN.
2) PRESS and Release the AUTO / DELETE. The
corresponding LED in screen will flash.
3) Adjust the FADE TIME and the SPEED Sliders to your
desired CHASE rate.
NOTE A - Never adjust the FADE TIME (last active slider
on right side of Controller) slower then the SPEED
setting Slider (second to last Slider on Right).
Otherwise your CHASES will not be completed
before each new scene is sent.
NOTE: B – If you wish to include ALL your CHASES. Press
AUTO / DELETE before selecting a CHASE.
3
RUNNING CHASES:
MUSIC RUN CHASES: Triggered by the
Music being played. Built in Microphone is
Located between Fixture switches 1 and 7 (hole
with no LED)
1) Press one of the six (6) CHASE Buttons to select the
CHASE desired.
2) Press and Release the MUSIC / Bank-Copy Button
3) The corresponding LED will FLASH in the LCD.
The CHASE will now run via the Sound / Music.
(10)
3
ADVANCING/CHANGING to Different CHASE:
AUTO RUN CHASES:
1) Select and Press the Chase that is active (running)
( LCD drops first number of the 4 numbers displayed.)
2) Select and Press the next CHASE you want to start.
(LCD adds new first number of this chase).
NOTE: When you exit a CHASE by Pressing the CHASE
Button, the Controller will automatically run the
SCENES that are in the last bank accessed.
To stop the movements of the light, either use the
BLACKOUT button or Press MUSIC if in the Music
Mode or in the AUTO Mode if in the AUTO MODE
3
MIDI CHANNEL SETTING
MIDI RUNNING
4) Press and HOLD the MIDI / Add Button. The third and
Fourth digits on the LCD display will FLASH – indicating
MIDI Mode.
5) Use the UP or Down Buttons to select the Midi channel
(1 – 16) you would like to use / run.
6) Press and HOLD the MIDI / Add Button once more to end
MIDI mode
3 MIDI CHANNEL SETTING
NOTE “ON”: RECEIVE NOTE “ON” SIGNALS TO EXECUTE
CORRESPONDING FUNCTIONS THE C-192
DMX CONTROLLER RECIEVES ONLY MIDI NOTES AND
YOU MIGHT WANT TO TRANSPOSE YOUR KEYBOARD
TO FIND THE PROPER MIDI NOTE.
4
TROUBLE SHOOTING / OFTEN ASKED QUESTIONS:
COLORS DON’T RESPOND WHEN FADERS ARE MOVED
MAKE SURE DMX ADDRESS IS CORRECT / DIP SWITCHES
IF XLR CABLE IS MORE THEN 30 METERS (100FT), CHECK
TO SEE IF TERMINATED CORRECTLY.
MIRRORS DON’T RESPOND WHEN SLIDERS ARE MOVED
MAKE SURE DMX ADDRESS IS CORRECT / DIP SWITCHES
MAKE SURE SPEED IS ADJUSTED, IF AVAILABLE FOR
FASTER MIRROR MOVEMENT. NOT ALL UNITS HAVE
SPEED ADJUSTMENT
(11)
