AL7020S, AL7024S Designer’s Guide
Doc. No. DG_7024E Altec Electronic AG Seite 29 / 32
6 6 . . M M O O D D U U L L E E D D I I M M E E N N S S I I O O N N S S
F IGURE 6-2. M ECHANICAL DRAWINGS
7.0 mm
Top View
Pin 1
2.0
Top View
Dimensions in Millimeters
