Tesira EX-MOD – SPECIFICATIONS





7

Tesira EX-MOD Specifications

Frequency Response:
20Hz to 20kHz @ +4dBu

+0/-0.25dB

Phantom Power:*

+48 VDC (7mA/input)

THD+N (22Hz to 22kHz):
@ 0dB gain, +4dBu in
@ 54dB gain, -50dBu in

< 0.006%
< 0.040%

Crosstalk
(channel to channel @
1kHz):

0dB gain, +4dBu input
54dB gain, -50dBu input




< -85dB
< -75dB

EIN (20Hz~20kHz, 66dB
Gain, 150Ω):*

< -125dBu Input Gain Range (6dB

Steps):*

0 - 66dB

Dynamic Range
(20Hz to 20kHz, 0dB):*

> 108dB

Sampling Rate:

48kHz

Tail Length:**

up to 300ms A/D – D/A Converters:

24-bit

Convergence:**

up to 100dB/sec Power Consumption

(100~240VAC 50/60Hz):

< 40W

Input Impedance
(balanced):*

8kΩ Compliance:

FCC Part 15B (USA)

Industry Canada CS-03

(Canada)

CE marked (Europe)

UL and C-UL listed (USA &

Canada)

RCM (Australia)

EAC (Eurasian Customs

Union)

RoHS Directive (Europe)

Output Impedance
(balanced):***

200Ω

Maximum Input*:

+24dBu

Maximum Output***

+24dBu

Overall Dimensions:

Height: 1.75 inches (44 mm)

Width: 19.0 inches (483 mm)

Depth: 10.5 inches (267 mm)

Weight: 7 lbs (3.2 kg)


* Specification applies to EIC-4, EEC-4, or input channels of EIOC-4
** Specification applies to EEC-4
*** Specification applies to EOC-4 or output channels of EIOC-4
