Abt VP30 - Manual (Page 35)

3
26 sdi 576i (PAL/SECAM
27 HdMi 480i (NTSC)
28 HdMi 576i (PAL/SECAM)
29 HdMi 480p (NTSC)
30 HdMi 576p (PAL/SECAM)
31 HdMi 720p (ATSC)
32 HdMi 1080i (ATSC)
33 HdMi VGa
34 HdMi sVGa
35 HdMi xGa
36 HdMi sxGa
37 HdMi 2 480i (NTSC)
38 HdMi 2 576i (PAL/SECAM)
39 HdMi 2 480p (NTSC)
40 HdMi 2 576p (PAL/SECAM)
41 HdMi 2 720p (ATSC)
42 HdMi 2 1080i (ATSC)
43 HdMi 2 VGa
44 HdMi 2 sVGa
45 HdMi 2 xGa
46 HdMi 2 sxGa
47 HdMi 3 480i (NTSC)
48 HdMi 3 576i (PAL/SECAM)
49 HdMi 3 480p (NTSC)
50 HdMi 3 576p (PAL/SECAM)
51 HdMi 3 720p (ATSC)
52 HdMi 3 1080i (ATSC)
53 HdMi 3 VGa
54 HdMi 3 sVGa
55 HdMi 3 xGa
56 HdMi 3 sxGa
57 HdMi 4 480i (NTSC)
58 HdMi 4 576i (PAL/SECAM)
59 HdMi 4 480p (NTSC)
60 HdMi 4 576p (PAL/SECAM)
61 HdMi 4 720p (ATSC)
62 HdMi 4 1080i (ATSC)
63 HdMi 4 VGa
64 HdMi 4 sVGa
65 HdMi 4 xGa
66 HdMi 4 sxGa
There is a separate set of settings not just for each input but for each format as well. This provides a
lot of flexibility but is complex. For example, you can make settings for an input with an NTSC source,
but when the source is changed to PAL, you must specify new settings.
Each input/format settings contains the information shown in Table 10.
Table 4. Format Settings
Setting Description
Picture Control
brightness
Contrast
saturation
Hue
sharpness
Chroma error Correction
Y/C Delay
Display Profile Profile 1 - 4 or User
Audio Select Audio 1 - 4
Audio Delay
Overscan
VCR Mode
Film Mode
Input AR Preset
Preset 1 - 4 or User Preset Note 1
