Bike Bike Rack
Product
Hoop Rack
Capacity
2-4 Bikes
Materials
1.5” OD 11 Gauge Tube. All open ends are capped to
prevent moisture from entering. All welds are MIG welds
around entire circumference of joined pieces.
Finishes
An after fabrication hot dipped galvanized finish is our standard
option.
250 TGIC powder coat colors, thermoplastic coating, PVC dip,
and stainless steel finishes are also available as alternate
options.
Our powder coat finish assures a high level of adhesion
and durability by following these steps:
1. Sandblast
2. Epoxy primer electrostatically applied
3. Final thick TGIC polyester powder coat
Stainless Steel: 304 grade stainless steel material finished
in either a high polished shine or a satin finish.
Installation
Methods
Each rack has two 2.5” x 6” mounting brackets double
gusset welded to the “wheels”. The brackets are 40”
apart. Each bracket is anchored to the ground with two
anchors. Anchors are included with each rack
Space Use
& Setbacks
Wall Setbacks:
For racks set parallel to a wall:
Minimum: 24”
Recommended: 36”
For racks set perpendicular to a wall:
Minimum: 64” (to allow maximum capacity of 4 bikes)
Distance Between Racks:
Minimum: 24”
Recommended: 36”
Street Setbacks:
Minimum: 36”
