American Bicycle Security Company
P.O. Box 7359
Ventura, CA 93006
Ph: (800) 245-3723 or (805) 933-3688
Fax: (805) 933-1865
Arc Rack
Product
Arc Rack
Capacity
2 Bikes
Materials
2” x 2” x 3/16” square tube
Finishes
An after fabrication hot dipped galvanized finish is our standard
option.
250 TGIC powder coat colors, thermoplastic coating, PVC dip,
and stainless steel finishes are also available as alternate
options.
Our powder coat finish assures a high level of adhesion
and durability by following these steps:
1. Sandblast
2. Epoxy primer electrostatically applied
3. Final thick TGIC polyester powder coat
Stainless Steel: 304 grade stainless steel material finished
in either a high polished shine or a satin finish.
Installation
Methods
In ground mount is embedded into concrete base. Specify in
ground mount for this option.
Foot Mount has two 3.5”x6”x.25”
feet with two anchors per
foot. Specify foot mount for this option.
Space Use
& Setbacks
Wall Setbacks:
For racks set parallel to a wall:
Minimum: 24”
Recommended: 36”
For racks set perpendicular to a wall:
Minimum” 28”
Recommended: 42”
Distance Between Racks:
Minimum: 24”
Recommended: 36”
Street Setbacks:
Minimum: 24”
Recommended: 36”
