51
Command List
When using Digital Zoom Separate Mode
(CAM_DZoomPos Inq)
Magnification Position Data
Ч
1 00
Ч
2 80
Ч
3 AA
×
4 C0
×
5 CC
×
6 D5
×
7 DB
×
8 E0
×
9 E3
×
10 E6
×
11 E8
×
12 EB
Lens Control
Others
Title Setting
Vposition 00 to 0A
Hposition 00 to 17
Blink
00: Does not blink
01: Blinks
00 White
01 Yellow
02 Violet
Color 03 Red
04 Cyan
05 Green
06 Blue
Zoom Position
0000 to 4000 to 7AC0
Wide end Optical Tele end Digital Tele end
Focus Position
1000 to C000
Far end Near end
1000: Over Inf
2000: 8.0 m
3000: 3.5 m
4000: 2.0 m As the distance on the left
5000: 1.4 m will differ due to
Focus Near 6000: 1 m temperature characteristics,
Limit 7000: 80 cm etc., use as approximate
8000: 29 cm values.
9000: 10 cm * The lower 1 byte is fixed
A000: 4.7 cm at 00.
B000: 2.3 cm
C000: 1.0 cm
R,B gain 00~FF
Aperture 00~0F
Pan/Tilt Position (Reference values)
Pan Position Data Tilt Position Data Tilt Position Data
(Image Flip: OFF) (Image Flip: ON)
Angle +170° 08DB – –
+150° 07DB – –
+90° 04B0 04B0 –
+30° 0190 0190 0190
+10° 0085 0085 0085
+0.075° 0001 0001 0001
0° 0000 0000 0000
–0.075° FFFF FFFF FFFF
–10° FF7B FF7B FF7B
–30° FE70 FE70 FE70
–90° FB50 – FB50
–150° F830 – –
–170° F725 – –
A + indicates a pan to the right and a tilt upward on the monitor screen.
A – indicates a pan to the left and a tilt downward on the monitor screen.
Pan/Tilt Status Code List
P Q R S
0 - - - - - - - 0 - - - - - - 1 A Pan movement all the way to the left
0 - - - - - - - 0 - - - - - 1 - A Pan movement all the way to the right
0 - - - - - - - 0 - - - - 1 - - A Tilt movement all the way up
0 - - - - - - - 0 - - - 1 - - - A Tilt movement all the way down
0 - - - - - - - - - 0 0 - - - - Pan movement is correct
0 - - - - - - - - - 0 1 - - - - Pan position cannot be detected
0 - - - - - - - - - 1 0 - - - - The Pan mechanism is abnormal
0 - - - - - 0 0 0 - - - - - - - The Tilt movement is correct
0 - - - - - 0 1 0 - - - - - - - The Tilt position cannot be detected
0 - - - - - 1 0 0 - - - - - - - The Tilt mechanism is abnormal
0 - - - 0 0 - - 0 - - - - - - - No movement instructions
0 - - - 0 1 - - 0 - - - - - - - In the midst of a Pan/Tilt
0 - - - 1 0 - - 0 - - - - - - - Pan/Tilt completed
0 - - - 1 1 - - 0 - - - - - - - Pan/Tilt failed
0 - 0 0 - - - - 0 - - - - - - - Not initialized
0 - 0 1 - - - - 0 - - - - - - - Initializing
0 - 1 0 - - - - 0 - - - - - - - Initialization completed
0 - 1 1 - - - - 0 - - - - - - - Initialization failed
( - : optional)
