LED Downlight 2000 Series Area Lighting
： Bank Counter
Designed Illumination
：350lx
Designed Example
：Bank Counter
10m
1m 380
380
340 340 300
260
300
260
4m ※The curve graph shows the illumination unit ：（lx）
Lamp Traditional Lamp
Light source Traditional Light Source
Light Source Luminous Flux 1600lm
Lifetime 8000hrs
Installation Height 3m
Maintained Average luminance 352lx
Power Consumption 420W
Isolux diagram Face
亮度
相 同
Designed
Illumination ：
20lx
S am e
B right nes s
as 350lx
above
Energy
saving
about
50 ％
Same
number of
fixture
Lifetime
about 5
times longer
Isolux diagram Face
※The curve graph shows the illumination unit ：（lx）
Lamp DL-2006E1-21
Light source LED
Light Source Luminous Flux 1800lm
Lifetime 35000hrs
Installation Height 3m
Maintained Average luminance 363lx
Power Consumption 210W
10 units
Traditional Lamp 42W Vertical Section
10m
1m 400
400
360 360 320
280
320
280 10 units
LED Downlight 6 " 21W
( DL-2006E1-21 )
