Silver King SKFCB60H - Manual (Page 3)

2
Electrical Connections
Be sure to check the data plate, located on the liner of the cabinet, for required voltage prior to connecting the unit to a power
source. The specifications on the data plate supersede any future discussion.
The standard unit is equipped with an eight (8) foot power cord that requires a 115 Volt, 60 Cycle, 1 Phase, properly grounded
electrical receptacle. The power cord comes with a 3 prong plug for grounding purposes. Any attempt to cut off the grounding
spike or to connect to an ungrounded adapter plug will void the warranty, terminate the manufacturer’s responsibility and could
result in serious injury.
The circuit must be protected with a 15 or 20 ampere fuse or breaker. The unit must be isolated on a circuit and not plugged into an
extension cord.
OPERATION
Initial Start Up:
After satisfying the installation requirements, the unit is ready to start. The unit will start when the power cord is connected to the
required power source. If the compressor does not start when the unit is initially plugged in, check to make sure that the power
switch is not in the ‘off ‘ position. Allow the unit to run a minimum of two hours before loading it with product.
Temperature Control
The Electronic Temperature Control is located on the front of the cabinet and is factory set to maintain an average cabinet
temperature of -5 to 5 Deg. F. Temperature may rise with prolonged drawer opening or following a defrost cycle.
Temperature Adjustment
Pressing the SET button for one second will display the set-point value.
After pressing the SET button for a few seconds, the set-point value blinks;
Press the UP of DOWN button to increase or decrease the set-point value; press the SET button once/more to confirm the new
value. Allow the unit a minimum of one hour to respond to a control setting adjustment.
Manual Defrost
Besides the automatic defrost; it is possible to activate a manual defrost by pressing the DOWN (melting snowflake) button for more
than 5 seconds.
Continuous Cycle
The compressor can be put into a continuous run for 4 hours by pressing the UP (snowflake) button for more than 5 seconds.
Defrost
Your Silver King unit is an automatic defrost unit. No additional plumbing is required. Defrost water is collected in a pan located in
the compressor compartment where it is evaporated into the room air. It is important that the unit be level so the condensate can
drain properly.
MAINTENANCE
Preventative maintenance is minimal although these few steps are very important to continued operation and maximizing the life of
the appliance.
Cabinet Surfaces
The cabinet’s interior and exterior are stainless steel. These surfaces should be cleaned periodically with a solution of warm water
and mild soap. After cleaning the surfaces should be rinsed with clean water and wiped dry with a soft cloth. Stainless steel
cleaners can also be used. Should a surface become stained, do not attempt to clean with an abrasive cleaner or scouring pad.
Use a soft cleanser and rub with the grain of the metal to avoid scratching the surface. Always rinse well and dry after cleaning.
Do not use chlorinated cleaners.
Condenser
Periodically, the condenser coil must be cleaned. The condenser is located behind the front cover at the right front of the unit.
Remove the front cover by removing the two (2) screws at the left side of the cover and swinging the cover off the cabinet. The
MODEL SERIAL NO. DATE INSTALLED
