12
JBZ Joint Installation
If the unit is shipped in one piece, skip this section. If the unit is shipped as
two separate pieces, continue with this section.
Test Fit
Dry fit the two sections of the sink together to be sure that the joint has not
been damaged in shipping. The lip of the rinse tank will slide over the
edge of the wash tank.
Check the alignment and fit of the two sections. It may be necessary to
adjust the leveling feet to achieve a correct fit. Ensure that all the feet are
adjusted to firmly contact the floor.
Separate the two sections in order to apply sealant to the joint.
Mating and Sealing the Joint
Apply the grey-colored NSF approved sealant (supplied with the unit) to
the underside of the JBZ lip and all interior surfaces of the wash tank trim
plate.
SEALANT APPLIED TO INTERIOR
SURFACE OF TRIM PLATE SEALANT APPLIED TO
UNDERSIDE OF JBZ JOINT AND
FACE OF THE END PLATE
