Page 26

4 Coat the shaft sleeve lightly with lube. Install the mechanical seal on the

shaft sleeve using your hand to push against the seal face. Make sure
rubber seal bellows are seated against sleeve shoulder and carbon seal
face is not scratched or chipped.

5 Slide the shaft sleeve onto the motor shaft and install the O-ring on the

groove of the sleeve. Using lube or grease on the O-ring will help hold the
ring in place temporarily until the impeller is secured.

6 Install the key on the motor shaft and place the impeller on the motor

shaft engaging the key.

7 Put the gasket on the washer head cap screw.
8 Install the impeller cap screw by holding the impeller, push the impeller

back against the sleeve and the other hand tighten the screw to 23-ft lbs.
of torque. (Do not over tighten as this could cause the gasket to squeeze
out, become deformed and not seal properly.

Slide the pump end on the (3) studs of the volute. The motor junction box

should be at the bottom.

10 Install (3) nuts on the stud and tighten to 23-ft.lbs.
