34
Parts List
Pump Parts
29501 MOTOR-LEESON 2HP 230V
29507 MOTOR-LEESON 2HP 208V
26572 FAN-BALDOR MOTOR
29743 PUMP WITH MOTOR, IMPELLER AND CASING GASKET (W/B 2HP)
21356 FRAME ADAPTOR WITH WEAR RING
22446 SHAFT SLEEVE
25976 SNAP RING
21884 IMPELLER
25975 IMPELLER KEY
19345 GASKET-PUMP CASING (W)
24463 SEAL KIT-PUMP
RS1011 PUMP CLEANOUT PLUG
Common Control Parts
24223 TIMER
29444 CONTACTOR-HEATER
23898 CONTACTOR-PUMP
29446 OVERLOAD
23727 SWITCH BLOCK-HEATER
21457 SWITCH OPERATOR-HEATER
23727 SWITCH BLOCK-START
23896 SWITCH BLOCK-STOP
23894 START SWITCH-PUSH BUTTON
23895 STOP SWITCH-PUSH BUTTON
19885 LIQUID LEVEL CONTROL
23987 LIQUID LEVEL SENSOR PROBE
23988 GASKET-LIQUID LEVEL SENSOR PROBE
23986 HEAT CONTROL
24030 THERMOCOUPLE
19443 GASKET-THERMOCOUPLE
28925 HEAT BOX LEFT HAND UNITS
28926 HEAT BOX RIGHT HAND UNITS
24817 HEATER ELEMENT
20280 FUSE 3 BUSSMAN ABC 2
26998 CIRCUIT BREAKER 30A
27244 TRANSFORMER 24V
100-343 "O" RING - LEVER DRAIN
