Spare parts 21, Sp ares & repl a cement – Merrychef eikon e4 User Manual
Page 43
Service & Parts Manual original Instructions
Part Number 32Z3813 US
Issue 1
43
SP
ARES &
REPL
A
CEMENT
SPARE PARTS
21
Parts list & recommended minimum stock holding & Service Kits
Exploded
BOM No.
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st Aid/
To Go
Box
Service
Centre
kit
1
105005
M3 CAGE NUT
10
EA
10
30
60
4
30Z0240
MICROSWITCH
2
EA
2
6
12
2
4
6
30Z0503
SWITCH ON/OFF ROCKER DPST
1
EA
1
3
6
1
1
7
30Z1177
20 AMP LITTLEFUSE FLM020
2
EA
2
6
12
2
4
8
30Z1178
30A FUSE HOLDER
2
EA
1
3
6
1
2
10
30Z1340
FILTER 16A SCREW MOUNT
5
EA
2
6
12
1
4
11
30Z1415
MAGNETRON 2M303H
2
EA
1
3
6
1
2
12
30Z1425
LV TRANSFORMER
1
EA
1
3
6
1
2
13
30Z1427
MAGNETRON OVERHEAT STAT
2
EA
1
3
6
1
1
14
30Z1430
MICROSWITCH (LARGE)
1
EA
1
3
6
1
1
15
30Z1439
RELAY 12V OMRON
2
EA
1
3
6
1
2
16
30Z5000
SMART RELAY BOARD SRB
1
EA
1
3
6
1
17
30Z5002
TOUCH SCREEN & PCB
1
EA
1
3
6
1
18
31Z0115
INSULATOR PAD
2
EA
2
6
12
19
31Z0630
3 WAY CHOC BLOC
1
EA
2
6
12
1
20
31Z0186
SILASTIC BLACK (DOOR SEAL)
TUBE
1
3
6
1
1
21
31Z0477
4 WAY MAINS TERMINAL BLOCK
1
EA
1
3
6
1
22
31Z0600
USB ADAPTOR MODULE
1
EA
1
3
6
1
23
31Z0620
BTS UI SRB CABLE (WHITE)
1
EA
1
3
6
1
1
24
31Z1255
PG21 CABLE GLAND BLACK
1
EA
1
3
6
25
31Z1256
PG21 CABLE GLAND NUT
1
EA
1
3
6
26
31Z1259
SHEET COVER CAP 12MM DIA
4
EA
4
12
24
27
31Z1307
ETHERNET HOLE PLUG
1
EA
1
3
6
28
31Z3154
M4x6 SET SCREW S/S A2 (IMPINGER)
2
EA
1
3
6
1
29
32Z1066
DOOR HANDLE
1
EA
1
3
6
30
32Z4028
HALF SIZE GASTRONOM DISH
1
EA
1
3
6
31
32Z7062
PERSONALITY MODULE SRB e4
1
EA
1
3
6
1
32
32Z7065
PERSONALITY MODULE BTS e4
1
EA
1
3
6
1
33
DR0005
4 COIL DUAL HEAT ELEMENT 3.2kW
1
EA
1
3
6
1
34
DR0006
REED SWITCH
1
EA
1
3
6
1
1
35
DR0007
MERRYCHEF BADGE
1
EA
1
3
6
36
DR0008
MERRYCHEF BADGE SLIDER
1
EA
1
3
6
37
DR0009
MERRYCHEF BADGE GUIDE
1
EA
1
3
6
38
DR0010
MERRYCHEF BADGE SEAL
1
EA
1
3
6
39
DR0011
TOUCHSCREEN OVERLAY
1
EA
2
6
12
1
40
DR0021
HARMONISED SPEAKER
1
EA
1
3
6
1
41
DR0043
OVERHEAT STAT LARGE
1
EA
1
3
6
1
1
42
DV0061
IMPINGER THUMB NUT
2
EA
2
6
12
1
43
DV0168VIT
DOOR CHOKE PRESSED (VITREOUS)
1
EA
0
1
2
44
DV0187
TOP PANEL (PRESSED)
1
EA
0
1
2
45
DV0202
CERAMIC PLATE RETAINER
4
EA
4
12
24
4
46
DV0239
IMPINGER FIXING - FAST THREAD
2
EA
1
3
6
1
47
DV0275
RACK V3
1
EA
1
3
6
48
SA3113
DOOR SEAL HT
1
EA
1
3
6
1
1
49
DV0366
GREASE FILTER HOUSING (EASY OUT)
1
EA
1
3
6
50
DV0370
LOWER IMPINGER HANDLE
1
EA
1
3
6
1
51
DV0397
CAST REAR DUCTING RH
1
EA
0
1
2
52
DV0403
CAST REAR DUCTING LH
1
EA
0
1
2
53
DV0437
LOWER FASCIA FINISHED
1
EA
0
1
2
54
DV0452
CAPACITOR CLIP
2
EA
2
6
12
