Page 5
- 5 -
E
EX
X 6
6880
0M
M
CONNECTING THE POWER
C
CA
AU
UT
TIIO
ON
N :: A
AS
S A
A P
PR
RE
EC
CA
AU
UT
TIIO
ON
N,, IIT
T IIS
S A
AD
DV
VIIS
SA
AB
BL
LE
E T
TO
O D
DIIS
SC
CO
ON
NN
NE
EC
CT
T T
TH
HE
E V
VE
EH
HIIC
CL
LE
E’’S
S B
BA
AT
TT
TE
ER
RY
Y B
BE
EF
FO
OR
RE
E
M
MA
AK
KIIN
NG
G C
CO
ON
NN
NE
EC
CT
TIIO
ON
N T
TO
O T
TH
HE
E
+
1122 V
VO
OL
LT
T S
SU
UP
PP
PL
LY
Y W
WIIR
RIIN
NG
G((F
Fiigg.. 11))
8 GAUGE
(Thicker if planning for additional Amplifiers) wire is recommended for
both the power and ground wires. 16 Gauge, for the remote turn-on wire. Both
types available at most Mobile Audio Dealers or Installation Shops.
G
GR
RO
OU
UN
ND
D::
To Vehicle Chassis
To avoid unwanted engine noise caused by ground loops, it is essential that the
Amplifier be grounded to a clean, bare, metal surface of the vehicle’s chassis.
NOTE
G
GR
RO
OU
UN
ND
D W
WIIR
RE
E S
SH
HO
OU
UL
LD
D N
NO
OT
T B
BE
E E
EX
XT
TE
EN
ND
DE
ED
D M
MO
OR
RE
E T
TH
HA
AN
N 33 F
FT
T.. (( 11 M
ME
ET
TE
ER
R))..
U
US
SIIN
NG
G T
TH
HIIS
S M
ME
ET
TF
FO
OD
D C
CA
AN
N C
CA
AU
US
SE
E T
TU
UR
RN
N O
ON
N A
AN
ND
D T
TU
UR
RN
N O
OF
FF
F T
TR
RA
AN
NS
SIIE
EN
NT
TS
S ((N
NO
OIIS
SE
E))
+
+1122 V
Vo
olltt ((F
Fu
usse
ed
d)) C
Co
on
nsstta
an
ntt P
Po
ow
we
err ::
To Battery (+)
Due to the power requirements of the Amplifier, this connection should be made
directly to the positive (+) terminal of battery. For safety measures, install an in-line
fuse holder (not included) as close to the battery positive (+) terminal as possible.
With an ampere rating not to exceed total value of fuses in amp.
Fuse : 25A x 3
R
Re
em
mo
otte
e T
Tu
urrn
n--O
On
n IIn
np
pu
utt:
To Power Antenna output of Car Stereo
This Amplifier is turned “ON” remotely when the vehicle’s stereo is turned “ON”.
NOTE
IF YOUR RADIO DOES NOT HAVE A 12 VOLT OUTPUT LEAD WHEN THE RADIO IS TURNED ON, “RMT”
TERMINAL ON THE AMPLIFIER CAN BE CONNECTED TO VEHICLE’S ACCESSORY CIRCUIT THAT IS
LIVE WHEN THE KEY IS “ON”.
