cEncoRp 1300 SR
TEChNICAL DATA
Machine Dimensions
Gantry
Control
Options
Utilities
Board handling
Spindle Motor Programming
Software Features
Standard Features
Camera-Assisted Teaching System (CATS)
Cencorp 1300 SR control software
Touch Screen
Ergonomic Operator Load / Unload
Program Teach Mode: Coordinates are taught
by physically moving the motors to the specific
coordinates, “teaching” the machine the positions.
Industrial computer
Broken Bit Detection
CE Certification
Manually or automatically step through
program to verify the program before
running production.
heavy Duty Multi-Axis Servo Gantry
Sliding table: Max panel size
500 mm x 500 mm (19.68” x 19.68”)
Voltage: 208-220, 3-phase, 60 hz, 20 Amps
380-400, 3-phase, 50 hz, 16 Amps
Windows® XP
Gantry motors: AC brushless servo motors
Event Log
Type: 33 mm ball-bearing spindle Width: 1300 mm (51.2”)
Panel thickness :
33 mm spindle: 1.5 mm (0.06”) max
45 mm spindle: Up to 4 mm (0.16”)
Tool change: Manual / Automatic option
Tool change: Manual / Automatic option
Optional: heavy duty spindle
Optional: heavy duty spindle
Touch Screen Monitor
Configuration: X, Y, Z
Tool Life Tracking
Cooling: Air cooled
Cooling: Air cooled
height: 1733 mm (69.8”)
Rotary table: Max panel size
350 mm x 450 mm (13.78” x 17.72”)
Router bit: Shank size 3.175 mm (1/8”)
Router bit: Shank size 3.175 mm (1/8”)
Ethernet Port
Flow: 85 l/min (3 SCFM)
Servo repeatability: ±0.03 mm (0.001”)
Diagnostic Tools
Max speed: Variable up to 50,000 RPM Depth: 1440 mm (56.7”)
Max component height: 10 mm (0.39”),
Bottom (tooling) side: 50.8 mm (2”),
Top (router) side: 10 mm (0.39”)
Routing speed: Up to 75 mm (3”)/sec
Routing speed: Up to 75 mm (3”)/sec
Type: 45 mm ball-bearing spindle
Type: 45 mm ball-bearing spindle
Pressure: 5.5 bar (80 PSI) clean, dry air
Vacuum Bag Life Tracking
Approx. weight: 1000 kilos (2200 lbs.)
Load height: 800/900 mm (31.5/35”)
Slew speed: Up to 1000 mm (39”)/sec
Slew speed: Up to 1000 mm (39”)/sec
Multi-Level Password Protection
Max speed: Variable up to 50,000 RPM
Max speed: Variable up to 50,000 RPM
Barcode Program Verification Software
Automatic Fixture Verification
Tall Component Clearance 20 mm
(applicable only with 45 mm spindle)
Specifications subject to periodic review and change without notice
cencorp corporation • Insinöörinkatu 8, FI-50100 Mikkeli, Finland • tel +358 20 7747 788, fax +358 20 7747 770 • www.cencorp.com
• [email protected] • Reg.no. 433811, VAT no. FI07496061
Main dimensions:
95
1677
1354
745
618 633 1404
