PT-LM1
Mobile SVGA LCD Projector
S P E C F I L E
Specifications
Power supply:
100 – 240 V AC, 50/60 Hz
Power consumption:
180 W (3 W for 120V, 5 W for 230 V, in standby mode with fan stopped)
Optical system:
Dichroic mirror separation/prism synthesis system
LCD panel:
Panel size:
0.55˝ diagonal (4:3 aspect ratio)
Display method:
Transparent LCD panel (x 3, R/G/B)
Drive method:
Active matrix
Pixels:
480,000 (800 x 600) x 3, total of 1,440,000 pixels
Pixel configuration:
Stripe
Lens:
Manual zoom/focus lens (1:1–1:1.2),
F 1.8–1.9, f 17– 20.4 mm
Lamp:
130 W UHM™ lamp
Screen size:
838 – 7,620 mm (33– 300 inches) diagonally, 4:3 aspect ratio
Throw distance:
1.17–10.99 mm (3´10˝–36´)
Colors:
Full color (16,777,216 colors)
Brightness:
1200 lumens
1
Center-to-corner uniformity ratio:
90%
Contrast ratio:
400:1 (full on/full off)
Resolution:
RGB:
800 x 600 pixels (1,600 x 1,200 pixels with compression)
Video:
600 TV lines (horizontal resolution)
Scanning frequency:
RGB:
Horizontal: 15 – 91 kHz, Vertical: 50 – 85 Hz
YP
B
P
R
:
480i (525i): f
H
15.75 kHz; f
V
60 Hz
576i (625i): f
H
15.63 kHz; f
V
50 Hz
480p (525p): f
H
31.5 kHz; f
V
60 Hz
576p (625p): f
H
31.25 kHz; f
V
50 Hz
720p (750p): f
H
45 kHz; f
V
60 Hz
1080i (1125i): f
H
33.75 kHz; f
V
60 Hz
1080i (1125i): f
H
28.125 kHz; f
V
50 Hz
S-Video/Video:
f
H
15.75 kHz; f
V
60 Hz (NTSC, NTSC 4.43, PAL-M, PAL 60)
f
H
15.63 kHz; f
V
50 Hz (PAL, SECAM, PAL-N)
Optical axis shift:
6:1 (fixed)
Keystone correction range:
Vertical: approx. ±30°
Installation:
Ceiling/desk, front/rear (menu selection)
Built-in speakers:
Size:
2.8 cm x 1, round (monaural)
Output power:
1.0 W
Terminals:
RGB IN:
D-sub HD 15-pin (female) x 1
RGB signal
G: 0.7 Vp-p (1.0 Vp-p for Sync on G), 75Ω
R, B: 0.7 Vp-p, 75Ω
HD, VD, SYNC: TTL, high impedance (positive/negative polarity)
YP
B
P
R
signal
Y: 1.0 Vp-p (including sync signal), 75Ω
P
B
, P
R
: 0.7 Vp-p, 75Ω
VIDEO IN:
RCA pin x 1, 1.0 Vp-p, 75Ω
S-VIDEO IN:
Mini DIN 4-pin x 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75Ω
AUDIO IN:
RCA (L, R) x 1, 0.5 Vrms, for RGB/VIDEO/S-VIDEO
Power cord length:
3 m
Cabinet material:
ABS/PC
Dimensions (W x H x D):
257 x 59 x 209 mm (10-3/32˝ x 2-11/32˝ x 8-7/32˝)
(protrusions not included, with lens cover detached)
Height including legs: 69 mm (2-11/16˝)
Weight:
1.6 kg (3.5 lbs.)
Operating environment:
Temperature:
0° – 40°C (32°–104°F)
Humidity:
20% – 80% (no condensation)
Remote Control Unit:
Power supply:
3 V DC (button battery x 1)
Operation range:
Approx. 7 m when operated from directly in front of the signal receptor
Dimensions (W x H x D): 40 x 86 x 6.5 mm (1-9/16˝ x 3-3/8˝ x 1/4˝)
Weight:
17.5 g (0.62 oz.) (including a battery)
Supplied accessories:
Power cord, Wireless remote control, Button battery for remote control,
RGB cable, Soft case
Optional accessories:
Replacement lamp unit: ET-LAM1
Ceiling mount bracket: ET-PKM1
Full-function wireless remote control: ET-RM200
Weights and dimensions shown are approximate.
Specifications are subject to change without notice.
As of October 2003
1: The figures are averages of all products at the time of shipment, and are indicated in accordance with JIS X6911: 2003
Data Projector Specifications Format. The measurement method and conditions are described in Appendix 2.
