DIMENSIONS
EXTERIOR
H x W x D:
45-1/8" x 15-3/4" x 33-5/8"
(1146mm x 400mm x 854mm)
BASKET DIMENSIONS
(
H
X
W
X
D
)
5-7/8" x 5-3/16" x 13-13/16"
(149mm x 131mm x 351mm)
#353 - 01/08
ASF-60E
E L E C T R I C O P E N F RY E R
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE
: 262.251.3800 800.558.8744
U
.
S
.
A
./
CANADA
FAX
: 262.251.7067 800.329.8744
U
.
S
.
A
.
ONLY
www.alto-shaam.com
Fry
Fry
Tech
Tech
STANDARD ACCESSORIES
■
■
Basket, Half-Size
(2
INCLUDED AS STANDARD
)
BS-27963
Brush Set
(
ONE
3-
BRUSH SET INCLUDED AS STANDARD
)
■
■
ANGLE BRUSH
BH-27382
■
■
SCRUB BRUSH
CE-27122
■
■
STRAIGHT BRUSH
BH-27121
O P T I O N S
■
■
Fry Pot Cover
5007596
■
■
Strainer/Skimmer
CE-27400
C A PA C I T Y
SHORTENING/OIL: 62 lb (28 kg)
MAXIMUM
C L E A R A N C E R E Q U I R E M E N T S
BACK
: 6" (152mm)
FRONT
: 25" (635mm)
6" (152mm)
REQUIRED ON ALL SIDES WHEN
ADJACENT TO COMBUSTIBLE SURFACES
.
I N S TA L L AT I O N R E Q U I R E M E N T S
Hood installation is required.
Fryer must be installed level.
A flexible connector must be installed and
secured to the building structure.
NOT FACTORY SUPPLIED
W E I G H T
EST
NET WEIGHT
SHIP WEIGHT
248 lb (113 kg)
330 lb (150 kg)
CARTON DIMENSIONS
:
39" x 22" x 55"
(991mm x 559mm x 1397mm)
ELECTRICAL
VOLTAGE
PHASE
CYCLE
/
HZ
AMPS
kW
208-220 (
ETL
)
3
60
47
17.93
at 208
3
60
45
16.2
at 220
3
60
47.6
18.2
240 (
ETL
)
3
60
43.1
17.93
380-415
at 380
3
50
20.4
15.4
at 415
3
50
25.4
18.3
440-480 (
ETL
)
at 440
3
60
40.8
31
at 480
3
60
44.4
37
No cord and plug
