5
Use the ENTER button to select a highlighted menu, and to move between individual items within a menu. Use
the UP/DOWN buttons to select/deselect an item, or to increase/decrease the value of an item.
Contrast and Brightness
Contrast Controls the display contrast.
Brightness Controls the display brightness.
Video Adjustment
Auto Adjust Automatically sets display image size, position, and fine adjustment. Contrast
and brightness are not adjusted.
Left/Right Controls horizontal position.
Up/Down Controls vertical position.
Horizontal Size Increases or decreases the horizontal size of the image.
Fine Controls the vertical fine adjustment. May improve picture detail in emulation
modes.
OSD Tool
OSD Left/Right Adjusts the default horizontal position of the OSD on the display.
OSD Up/Down Adjusts the default vertical position of the OSD on the display.
OSD Timeout Determines time (in seconds) that OSD waits before automatically closing after
no action has been performed.
Factory Reset Recalls original factory settings of image parameters.
OSD Language Selects the OSD menu language—English, French, German, Italian, Spanish,
Japanese, Traditional Chinese, or Simplified Chinese.
Color Adjustment Adjusts preset color temperature of the image. Available choices are 9300,
7500, 6500, and 5500° Kelvin (K). A User mode allows custom setup of each
color component of the image—Red, Green and Blue. Default setup for this
parameter is 6500°K. Do not adjust color temperature unless you have a specific
need to do so.
Audio Adjustment
Volume Adjusts the loudspeaker volume.
Mute ON/OFF Mute ON turns off the audio function. Mute OFF restores the audio function.
Auto DIM
Auto Dim Turns the Auto-Sensing Brightness Adjustment circuit ON or OFF.
Dimming Range Menu shows sensed light level, and brightness setting as a percentage of full
scale (same setting as Brightness in Contrast and Brightness menu when Auto
DIM is OFF). With Auto DIM ON, brightness is now controlled by the light sensor
located at top center of the front bezel. See additional discussion of the Auto-
Sensing Brightness Adjustment feature further in this section.
