Specifications
Model name KDL-40X4500 KDL-46X4500 KDL-55X4500 KDL-70X4500
System
Panel system LCD (Liquid Crystal Display) Panel
TV system Analogue: B/G, I, D/K
Digital: DVB-T
Colour/video system Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58,
NTSC4.43 (only video input)
Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4
Channel coverage Analogue:B/G: VHF: E2 to E12 / UHF: E21 to E69 /CATV: S01 to S03, S1 to S41
I: UHF: B21 to B69 /CATV: S01 to S03, S1 to S41
D/K: VHF: R1 to R12 / UHF: R21 to R69 /CATV: S01 to S03, S1 to S41
Digital: UHF
Sound output 10 W + 10 W, 12 W + 12 W (Woofer)
Input/Output jacks
Antenna/cable 75 ohm external terminal for VHF/UHF
1 S video input (4-pin mini DIN)
1, 2, 3 Video input (phono jacks)
1, 2 Supported formats: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Y: 1 Vp-p, 75 ohms, 0.3V negative sync/P
B /C B : 0.7 Vp-p, 75 ohms/
P R /C R : 0.7 Vp-p, 75 ohms
1, 2, 3 Audio input (phono jacks)
HDMI IN1, 2, 3, 4 Video: 1080/24p, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Audio: Two channel linear PCM: 32, 44.1 and 48 kHz, 16, 20 and 24 bits
Analogue audio input (minijack) (HDMI IN 1 only)
PC Input (see page 52)
DIGITAL AUDIO OUT (OPTICAL) Digital optical jack
Video output (phono jack)
Audio output (phono jacks)
PC IN (RGB) PC Input (D-sub 15-pin) (see page 52)
G: 0.7 Vp-p, 75 ohms, non Sync on Green/B: 0.7 Vp-p, 75 ohms/
R: 0.7 Vp-p, 75 ohms/HD: 1-5 Vp-p/VD: 1-5 Vp-p
PC audio input (minijack)
DMPORT DIGITAL MEDIA PORT
USB port
i Headphones jack
LAN 10BASE-T/100BASE-TX connector (Depending on the operating environment of the
network, connection speed may differ. 10BASE-T/100BASE-TX communication rate
and communication quality are not guaranteed for this TV.)
Power and others
Power requirements 220 V – 240 V AC, 50 Hz
Screen size (measured diagonally) 40 inches (Approx.
101.6 cm) 46 inches (Approx.
116.8 cm) 55 inches (Approx.
138.8 cm) 70 inches (Approx.
177.8 cm)
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Power
consumption in “Home”/“Standard”
mode 210 W 270 W 370 W 600 W
in “Shop”/“Vivid” mode 230 W 350 W 480 W 680 W
Standby power consumption* 0.3 W (19 W when
“Quick Start” is set
to “On”) 0.6 W (20 W when
“Quick Start” is set
to “On”) 0.7 W (22 W when
“Quick Start” is set
to “On”) 0.7 W (40 W when
“Quick Start” is set
to “On”)
Dimensions
(Approx.)
(w × h × d) with Table-Top Stand 1,128 Ч 655 Ч
279 mm 1,259 Ч 737 Ч
315 mm 1,486 Ч 855 Ч
356 mm 1,850 Ч 1,065 Ч
401 mm
without Table-Top Stand 1,128 Ч 603 Ч
125 mm 1,259 Ч 685 Ч
144 mm 1,486 Ч 803 Ч
147 mm 1,850 Ч 1,012 Ч
153 mm
Mass (Approx.) with Table-Top Stand 27.0 kg 38.0 kg 54.0 kg 86.5 kg
without Table-Top Stand 23.5 kg 33.0 kg 47.5 kg 72.5 kg
Supplied accessories See “1: Checking the accessories” on page 4.
(Continued)
