Installation and Connection Instructions
36
Connections
The water inlet and drain hoses, as well as the mains cable must be con-
nected beside the dishwasher as there is insufficient space behind the
appliance.
The plumbing and electrical installation example given below can only
be regarded as a recommendation; the actual situation where the dish-
washer is to be installed will define the exact installation (available
connections, local electricity and water board regulations for connect-
ing up appliances, etc.).
Two 45° or Straight Connections,
Outer ø 19 mm, Length 30 mm
Double tap Water drain Water inlet
Water
drain Water
inlet Mains
cable Mains
cable Mains socket
